Portable Anti-Drone System for 2.4GHz / 5.8GHz Threats and Beyond
In an era where consumer drones are increasingly used in unauthorized or malicious ways-ranging from privacy breaches to smuggling and illegal surveillance-real-time, mobile counter-drone solutions have become critical. The PDD-308A handheld anti-drone system is engineered to meet these modern security challenges with speed, accuracy, and ease of use.
Equipped with a high-gain external UWB antenna and a broad-spectrum detection module, the Portable Drone Signal Detector device can detect and analyze a wide range of drone signals including FPV video transmission (analog and digital), DJI, and Autel systems. It scans across 600 MHz to 6.2 GHz and responds with instant acoustic and visual alerts, ensuring rapid situational awareness without reliance on external networks.
Key Features:
- Full-band FPV & Spectrum Detection: Covers 900 MHz, 1.5 GHz, 2.4 GHz, 5.8 GHz, and expandable ranges to detect popular consumer drones.
- Real-Time Signal Analysis: Provides spectrum waveform (WAV) analysis to identify signal characteristics and drone types.
- Multi-Layer Alerts: Sound, LED light, and vibration warnings triggered upon drone detection.
- Portable & Tactical: Compact design, 300g weight (excluding antenna), IP55 protection, and optimized for rapid field deployment.
- 2km Detection Range: Ideal for perimeter security in critical zones such as airports, government buildings, and private estates.
Technical Specifications:
| Parameter | Details |
|---|---|
| Detection Modes | Spectrum + Analog FPV Signal Analysis |
| Drone Types Detected | DJI, Autel, and other consumer-grade drones |
| Detection Range | Up to 2,000 meters |
| Frequency Coverage | 600 MHz – 6.2 GHz (including 2.4 / 5.8 GHz) |
| Display | 2.0″ LCD, 240×320 resolution |
| Power Supply | Built-in 7.4V / 3000mAh lithium battery |
| Battery Life | Up to 4.5 hours continuous operation |
| Power Consumption | 5W |
| Operating Temp. | -20°C to +55°C |
| Protection Level | IP55 |
| Device Dimensions | 176.5 x 68.8 x 34.26 mm (without antenna) |
Why PDD-308A Matters
As urban airspace security becomes a global concern, the PDD-308A offers law enforcement, military units, and private security professionals a fast-deployable and network-independent solution for drone detection and classification. Unlike larger stationary systems, this compact unit is designed for mobile patrols, event security, and emergency response-where every second counts.
According to a 2024 Global Drone Threat Report, over 65% of unauthorized drone intrusions involved consumer drones operating on unlicensed FPV frequencies. The PDD-308A directly addresses this threat landscape with broadband coverage and low false alarm rates, even in electromagnetically complex environments.
Ideal For
- Critical Infrastructure Protection
- VIP/Private Security
- Border and Prison Monitoring
- Tactical Field Operations
- Airport and Airspace Management
